Aug 31, 2025Technical comparison of cement types 1 to 5 + Their standards
Portland cement is a family of hydraulic adhesives that, by hydrating its clinker phases—mainly alite (C₃S), belite (C₂S), aluminate (C₃A), and ferrite (C₄AF)—produce C-S-H gel and calcium hydroxide, forming the durable framework of concrete. The main factors distinguishing different cement types (1 to 5) are the chemical makeup of the clinker (especially the percentage of C₃A and the C₃S/C₂S ratio), the fineness of milling, and sometimes modifying additives. These differences directly influence the kinetics of early and final strength, heat of hydration (Q), behavior in aggressive sulfate/chloride environments, and the risk of thermal cracking.
In summary:
Types with higher C₃S and fineness (like Type III) develop strength more rapidly, but have higher Q and greater risk of thermal cracking.
Types with low C₃A (like Type V) provide higher sulfate resistance, but usually slower initial strength gain than high-heat types.
Low-heat types (like Type IV) are designed for mass concrete pours to control temperature gradients and thermal stress.
General-purpose types (Type I/II) offer a suitable balance of workability, strength, and durability, and are the most common economic choice for projects.
